Product info
-
Specifications
DN: 16 Size: 10 Inch: 5/8 Outer Ø [mm]: 26,5 Inner Ø [mm]: 15,9 bending radius [mm]: 160 working pressure [bar]: 20 burst pressure [bar]: 60 Safety factor: 3:1 Standard ferrule: XVTE10 / VC1-10 Weight [kg]: 0,27 Outer Ø max. [mm]: 26,5 Color cover: black Color inner tube: black Cover: Synthetic rubber Inner tube: Synthetic rubber MSHA-Approval: no Media: Water, oil, air, gasoline, fertilizers, herbicides Reinforcement: Layer of synthetic fiber braid Temperature range [°C]: -40°C to +100°C application: Oil, fuel and gasoline hoses at automobile and gas stations max operating temperature [°C]: +100°C number of layers: 1
