MST510-2-12BSP-S
Multi coupling series MST510 DN12/19 Cr III (male)

Product info

• Specifications

  DN:	12/19
  Size:	8/12
  working pressure [bar]:	250
  Thread + standard:	BSP female DIN 3852
  Thread [GA]:	2x 3/4"
  Pipe Ø R [mm]:	-
  Number of hydraulic inserts:	2
  Series:	2P
  Manufacturer ID number:	2P510-2-34-A M C
  max. number of electronic plugs:	2
  max. number of hydraulic plugs:	4
  l/min at ΔP=2 bar:	DN 12: 70 l/min; DN 19: 125 l/min
  Female or male coupling:	plug
  Maximum assignment of the multi-coupling:	4
  Product title long:	.
  Resistance against red rust [h]:	500 Std.
  Surface:	zinc plated, chrom 6-free
