Product info
-
Specifications
DN: 10 Size: 06 working pressure [bar]: 250 Thread + standard: BSP female DIN 3852 Thread [GA]: 1/2" Pipe Ø R [mm]: 12L Number of hydraulic inserts: 4 Number of electrical inserts: 1 Series: 2P Manufacturer ID number: 2PS06-1-4-12G M C max. number of electronic plugs: 1 max. number of hydraulic plugs: 4 l/min at ΔP=2 bar: DN 10: 40 l/min Female or male coupling: plug Maximum assignment of the multi-coupling: 4 Product title long: . Resistance against red rust [h]: 500 Std. Surface: zinc plated, chrom 6-free
