STDR-4SRPV08BSP12M

Product info

• Specifications

  Size:	3
  DN:	12
  Size:	08
  Inch:	1/2
  working pressure [bar]:	250
  Thread + standard:	BSP female thread, ISO / DIS 1179-1
  Thread [GA]:	1/2
  Outer Ø sleeve [mm]:	38,0
  Length sleeve [mm]:	109,0
  SW [mm]:	27
  Wrench size connection side sleeve:	27
  burst pressure sleeve uncoupled [bar]:	1000
  SW1 [mm]:	27
  Material:	C-steel, nitrified
  Material support ring:	PTFE
  Product title long:	Series STDR-4SRPV female coupling.
  Product title short:	female coupling
