Art. No.: VC-HDS6-CES25-25S
List number: 23420570
For general applications (eg. agricultural technology and construction industry), interchangeable according to ISO 14541
| Size: | 6 |
| DN: | 25 |
| Size: | 16 |
| Inch: | 1 |
| working pressure [bar]: | 333 |
| Thread + standard: | CE male thread heavy Series, DIN 3861 |
| Thread [GA]: | M36x2 |
| Pipe Ø R [mm]: | 25S |
| Outer Ø plug [mm]: | 60,0 |
| Connection thread: | M48x3 |
| Length plug [mm]: | 86,5 |
| SW2 [mm]: | 55 |
| Ø D [mm]: | 60,0 |
| SW1 [mm]: | 41 |
| l/min at ΔP=2 bar: | 189 |
| Material support ring: | PTFE |
Reserve technical changes.
