| Size: | 4 |
| DN: | 16 |
| Size: | 10 |
| Inch: | 5/8 |
| working pressure [bar]: | 250 |
| Thread + standard: | BSP internal thread DIN 3852 |
| Thread [GA]: | 3/4 |
| Outer Ø sleeve [mm]: | 42,0 |
| Length sleeve [mm]: | 80,0 |
| SW [mm]: | 36 |
| Wrench size connection side sleeve: | 36 |
| SW1 [mm]: | 36 |
| l/min at ΔP=2 bar: | 120 |
| Material: | C45 |
| Product title long: | Series VC-FF female coupling (ISO 16028). |
| Product title short: | female coupling |
Reserve technical changes.
